SPECIFICATIONS |
|
Product name: |
LED Linear Strip Light |
Art. Number: |
31018A (Customized lengths) |
Voltage: |
12V DC |
Wattage: |
12W/m |
LED QTY and Type: |
120pcs 2835LED/m. Every 3pccs(25mm) can be cut. |
Luminous Flux(lm) |
720lm/m |
Size: (mm) |
L (customized)xW19xH11.2mm |
Cutout:(mm) |
(L-10) x W16xH11mm |
Beam Angle: |
120 Degree |
Color Rendering Index: |
>80 |
LED Color Temperature: |
Warm White 3000K /Neutral White 4000K/ Cool White 6500K |
Material: |
Aluminum, PC |
Finish: |
Silver Grey |
IP rated: |
IP20 |
Certificate: |
CE, RoHS |
LED Lifetime: |
30,000 Hours |
Cable: |
1.5m 24# AWG cable and 91505-MP |
Requires drivers: |
Yes |
Sensor Mode: |
/ |
Detection range: |
/ |
Package Includes: |
Installation bracket and 2pcs screws and installation manual |
This items can be installed in wardrobe, cabinet, shelf etc. It is recessed mounted and the cutout is W16 xH11mm.
